OctoPi camera Stream

General Discussion
1

Hi, I am successfully running OctoPi. I would like to get the camera streaming setup but the settings are not pre-filled in on the OctoPi settings page.

On the OctoPrint https://octopi.octoprint.org/ it states

If a USB webcam or the Raspberry Pi camera is detected, MJPG-streamer will be started automatically as webcam server. OctoPrint on OctoPi ships with correctly configured stream and snapshot URLs pointing at it. If necessary, you can reach it under http://octopi.local/webcam/?action=stream and SSL respectively, or directly on its configured port 8080: http://octopi.local:8080/?action=stream.

Does OctoPi on DietPi come configured to stream the camera, if so, what is the stream URL.
thank you
Keith Ellis

2

Actually, someone has just pointed me to this page. Is this something that DietPi could setup automatically?

https://github.com/foosel/OctoPrint/wiki/Setup-on-a-Raspberry-Pi-running-Raspbian#webcam

Regards,
Keith Ellis

3

Octopi stream is the IP address of the server

http://LOCAL.LAN.IP.ADDRESS:8080/?action=stream for stream

http://LOCAL.LAN.IP.ADDRESS:8080/?action=snapshot

I believe you can change the port it goes out on as well…if you log into octopi as admin, there is a server config tab at the top where you can check/edit/tweak the video capture…I use a Logitech C270 USB as my capture device

Here are a few of my timelapses from octoprint running on a dual core laptop with 2gigs ram

GmSlBxnnq0Q

0PrDsTbiH5k

4

Yes, that is what I want, but DietPi does not install by default. Can this be an option during the DietPi OctoPi install?

5

I have to manually start mine each time I reboot…I will post up the command I put in (but have to copy/paste each time) to get it to start

nohup sudo /home/user1/mjpg-streamer/mjpg-streamer-experimental/mjpg_streamer -i "/home/user1/mjpg-streamer/mjpg-streamer-experimental/input_uvc.so -y -br auto -cb auto -wb auto -gain auto -q 100 -r SXGA" -o "/home/user1/mjpg-streamer/mjpg-streamer-experimental/output_http.so" &

I am using a Logitech C270 USB camera on a xubuntu on a desktop install (not sure if that matters)

I suppose I could add that command to the end of the /etc/init.d/octoprint startup script instead of /etc/rc.local

Just did a list of my files in /home/user1/mjpg-streamer/mjpg-streamer-experimental/ I have a file called output_http.so -p 8080 chmodded as 744 under user1:user1 so maybe that is the file that tells it what port to output the http stream on…so create a file with whatever port you want and try that

There are some dependencies that need to be met first…not installed “automatically” I believe…check your octoprint install directory
https://www.acmesystems.it/video_streaming

6

just added that code to the end of the /etc/init.d/octoprint file, it does work…it starts, however it will not kill it if I do service octoprint restart…so I either manually have to find the pid and kill it then service octoprint restart or reboot the machine

I also changed the SXGA to just XGA, the resolution in video streaming was so laggy in the ultra high resolution…much more snappy now

7

I have a feeleing you did not install OctoPi using DietPi. is this correct?

8

Yes…it’s on an old busted screen dual core laptop with 2gigs RAM and running xubuntu
I followed this walkthru

I added a sudoer user called user1 using this walkthru

Might be easier to install python with dietpi install script
